TestStation LX2

Engineered for High Pin Count, Complex Test

The TestStation LX2 is Teradyne’s largest pin count in-circuit test system. Configurable up to 15,360 pins utilizing UltraPin II 128HD pin cards for testing large, complex, and heavily-integrated printed circuit board assemblies.

Contact Sales
TestStation LX2

The TestStation LX in-circuit test system ideal for complex board testing:

  • Configurable up to 15,360 test pins
  • Compatible with TestStation LX test fixtures
  • Capable for testing large, complex, and heavily integrated PCBs
  • Safe, accurate, and reliable electrical test
  • Exceptional diagnostic accuracy
  • Designed for fast test throughput

The TestStation LX2 test system supports all the standard features of the TestStation platform, but is unique in the following ways:

  • Highest capacity test solution in the TestStation Family (15,360 pins)
  • High Speed Digital Subsystem and Clock/Sync/Trigger (CST) features of the TestStation platform come standard on this system
  • Equipped with built-in features for testing large, complex, and heavily integrated PCBs
  • Supports up to 30 pin card slots
  • Configurable with 128L, 128HD and 124 Hybrid pin cards
